McCormick Intl B90 Max
|
|
| Production | |
| Manufacturer | McCormick Intl (a part of Argo) |
| Utility tractor | |
| McCormick Intl B90 Max Engine | |
| Perkins 4.4L 4-cyl diesel | |
| Fuel tank | 23.8 gal 90.1 L |
 Engine details ... | |
| McCormick Intl B90 Max Transmissions | |
| 12-speed | |
| 12-speed mechanical shuttle | |
| 24-speed | |
 Transmission details ... |
| McCormick Intl B90 Max Power | |
| Engine | 83 hp 61.9 kW |
| PTO (claimed) | 77 hp 57.4 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | mechanical rear |
| hydraulic front and rear OptOptional | |
| Mechanical wet disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| Two-post ROPS. Available canopy. | |
| Photos | |
| No photos of the McCormick Intl B90 Max are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pressure | 2611 psi 180.0 bar |
| Valves | 1 or 2 |
| SCV flow | 13.8 gpm 52.2 lpm |
| Total flow | 20.2 gpm 76.5 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift | 5732 lbs 2600 kg |
| 8157 lbsOptOptional 3700 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| 540/750 (1.375) | |
| Dimensions & Tires | |
| 2WD Wheelbase | 92 inches 233 cm |
| 4WD Wheelbase | 71 inches 180 cm |
| Weight | 7326 lbs 3323 kg |
| Front tire | 12.4-24 |
| Rear tire | 18.4-30 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| B-Max Series published in 2011, by McCormick |
