New Holland T6.145


New Holland T6.145 tractor photo
2015 -
T6 Series
Row-Crop tractor
Series map:
T6.145
T6.155
116.0hp
125.0hp
Production
ManufacturerNew Holland
Row-Crop tractor
Original price$101,700 (2015 Value )
$112,546 (2015 Elite )
Variants
T6.145 Valueeconomy
T6.145 Plusmid-spec
T6.145 Elitepremium
T6.145 CVTAutoCommand
New Holland T6.145 Engine
FPT 4.5L 4-cyl diesel
Fuel tank52.5 gal
198.7 L
 58.6 gal*With auxiliary tank.
221.8 L
Exhaust fluid (DEF)9.7 gal
36.7 L
Engine details ...
New Holland T6.145 Transmissions
16-speed partial power shift
16-speed
32-speed
Transmission details ...
New Holland T6.145 Power
Engine116 hp
86.5 kW
PTO (claimed)95 hp
70.8 kW
Mechanical
Four-wheel drive
Final drivesinboard planetary
Wet disc brakes
Horizon cab standard with air-conditioning. Comfort Ride cab suspension optional on Plus and Elite models. ISOBUS II and AutoGuidance available on Plus and Elite models.
Photos
No photos of the New Holland T6.145 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typefixed displacement
 closed center load-sensing *Plus and Elite
Rear valves2 to 4
Mid valves0 to 3
Pump flow21.1 gpm
79.9 lpm
 29.9 gpm*CCLS Plus and Elite
113.2 lpm
Tractor hitch
Rear TypeII
 III/II
Rear lift (at ends)8338 lbs
3782 kg
 9213 lbs*Lift capacity on Plus and Elite models
4179 kg
Front Hitchoptional *On Elite models
DrawbarCat. 3
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Front PTOoptional *On Elite models
Dimensions & Tires
Wheelbase104 inches
264 cm
Suspension Wheelbase105.7 inches
268 cm
SuperSteer Wheelbase109.8 inches
278 cm
Weight10561 to 12514 pounds
Front tire380/85R28
Rear tire460/85R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps120
 150 *Elite
 200 OptOptional
Battery CCA1300
Battery volts12
