John Deere 7420 High-Crop



John Deere 7420 High-Crop tractor photo
2003 - 2007
7020 Series
High-Clearance tractor
Series map:
7420 High-Crop
135.0hp
Production
ManufacturerJohn Deere
High-Clearance tractor
Built in Waterloo, Iowa, USA
Variants
7420row-crop
7420HChigh-crop
John Deere 7420 High-Crop Engine
John Deere 6.8L 6-cyl diesel
Fuel tank54.7 gal
207.0 L
Engine details ...
John Deere 7420 High-Crop Transmission
16-speed four-speed power shift
Transmission details ...
John Deere 7420 High-Crop Power
Engine135 hp
100.7 kW
PTO (claimed)115 hp
85.8 kW
Mechanical
Four-wheel drive
Power steering
ComfortGard Cab standard with air-conditioning.
Photos
No photos of the John Deere 7420 High-Crop are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeload sensing
Rear valves2
SCV flow26.7 gpm
101.1 lpm
Tractor hitch
Rear TypeIII/II
Rear lift9950 lbs
4513 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/1000
Dimensions & Tires
Wheelbase113.6 inches
288 cm
Front tire320/90R46
Rear tire320/90R46
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps115
Battery CCA850
Battery volts12
References
7420 High-Crop references literature
High-Crop and High-Clearance Tractors published in 2004, by John Deere
