John Deere 5115ML


John Deere 5115ML tractor photo
2012 - 2025
Model year
5M Series
Orchard/Vineyard tractor
Series map:
5100ML
5115ML
100.0hp
115.0hp
Production
ManufacturerJohn Deere
Orchard/Vineyard tractor
John Deere 5115ML Engine
John Deere 4.5L 4-cyl diesel
Engine details ...
John Deere 5115ML Power
Engine (gross)115 hp
85.8 kW
PTO (claimed)100 hp
74.6 kW
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Two-post foldable ROPS.
Photos
No photos of the John Deere 5115ML are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel40 gal
151.4 L
Hydraulic system14 gal
53.0 L
Hydraulics
Typeopen center
Capacity14 gal
53.0 L
Pressure2900 psi
200.0 bar
Valves3 to 5
SCV flow18.4 gpm
69.6 lpm
Total flow24.7 gpm
93.5 lpm
Steering flow6.3 gpm
23.8 lpm
Steering press.1950 psi
134.5 bar
Tractor hitch
Rear TypeII
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/540E
Engine RPM540@2100
 540E@1645
Dimensions & Tires
Wheelbase90.6 inches
230 cm
Weight7950 lbs
3606 kg
Full dimensions and tires ...
5115ML Serial Numbers
Location:Serial number plate on the right side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps90
 120 *Available as a field-installed option.
Battery CCA950
Battery volts12
References
5115ML references literature
Specialty Tractors published in 2012, by John Deere
Specialty Tractors published in 2014, by John Deere
