John Deere 5100ML


No photo available
2012 - 2025
Model year
5M Series
Orchard/Vineyard tractor
Series map:
5100ML
5115ML
100.0hp
115.0hp
Production
ManufacturerJohn Deere
Orchard/Vineyard tractor
John Deere 5100ML Engine
John Deere 4.5L 4-cyl diesel
Fuel tank38 gal
143.8 L
Exhaust fluid (DEF)3.1 gal
11.7 L
Engine details ...
John Deere 5100ML Power
Engine (gross)100 hp
74.6 kW
PTO (claimed)85 hp
63.4 kW
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Two-post foldable ROPS.
Photos
No photos of the John Deere 5100ML are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2900 psi
200.0 bar
SCV flow18.4 gpm
69.6 lpm
Total flow24.7 gpm
93.5 lpm
Steering flow6.3 gpm
23.8 lpm
Steering press.1950 psi
134.5 bar
Tractor hitch
Rear TypeII
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/540E
Engine RPM540@2100
 540E@1645
5100ML Serial Numbers
Location:Serial number plate on the right side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps90
 120 *Available as a field-installed option.
Battery volts12
References
5100ML references literature
Specialty Series published in 2020, by John Deere
