Steiger Cougar 1000


Steiger Cougar 1000 tractor photo
1986
Four-wheel Drive (4WD) tractor
Series map:
Bearcat 1000
Cougar 1000
Panther 1000
235.0hp
280.0hp
335.0hp
Production
ManufacturerSteiger
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA
Variants
9150similar CaseIH model
Steiger Cougar 1000 Engines
Caterpillar 10.5L 6-cyl diesel
Cummins 10.0L 6-cyl diesel
Engine details ...
Steiger Cougar 1000 Power
Engine280 hp
208.8 kW
PTO (claimed)250 hp
186.4 kW
Mechanical
Four-wheel drive
Final drivesinboard planetary
Articulated power steering
Hydraulic disc brakes
Cab standard with air-conditioning.
Capacity
Fuel170 gal
643.5 L
Hydraulic system18 gal
68.1 L
Hydraulics
Typeclosed center load sensing
Capacity18 gal
68.1 L
Pressure2500 psi
172.4 bar
Valves2 to 4
Pump flow27 gpm
102.2 lpm
Tractor hitch
Rear TypeIII OptOptional
Power Take-off (PTO)
Rear PTOindependent OptOptional
Rear PTO Type1000
Dimensions & Tires
Wheelbase130 inches
330 cm
Weight23000 lbs
10432 kg
Front tire18.4x38
Rear tire18.4x38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps100
Batteries3
Battery CCA625
Battery volts12
References
Cougar 1000 references literature
Cougar 1000 published in 1986, by Steiger
Steiger Tractor, Inc. published in 1986
