CaseIH Steiger 540



CaseIH Steiger 540 tractor photo
2014 - 2023
Steiger 4WD Series
Four-wheel Drive (4WD) tractor
Series map:
Steiger 500
Steiger 540
Steiger 580
500.0hp
535.0hp
580.0hp
Production
ManufacturerCaseIH (a part of CNH)
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA
Original price was $418,167 in 2015
Variants
540wheeled tractor
540QTcrawler tractor
T9.600similar New Holland model
CaseIH Steiger 540 Engine
FPT 12.9L 6-cyl diesel
Fuel tank310 gal (early)
1173.4 L
 455 gal (late)
1722.2 L
Exhaust fluid (DEF)66 gal
249.8 L
Engine details ...
CaseIH Steiger 540 Transmission
16-speed full power shift
Transmission details ...
CaseIH Steiger 540 Power
Engine535 hp
398.9 kW
PTO (claimed)473 hp
352.7 kW
Drawbar (tested)441.44 hp
329.2 kW
PTO (tested)539.81 hp
402.5 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Steeringhydraulic articulated
Brakeshydraulic wet disc
 engine brake OptOptional
Trailer brakeshydraulic OptOptional
Surveyor Cab standard with air-conditioning.
Photos
No photos of the CaseIH Steiger 540 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typepressure flow compensated
Valves4 to 8
Pump flow42 gpm
159.0 lpm
 57 gpm*High Flow option
215.7 lpm
 113 gpm*TwinFlow option
427.7 lpm
SCV flow35 gpm
132.5 lpm
Tractor hitch
Rear TypeIVN
Rear lift (at 24"/610mm)19621 lbs
8900 kg
Rear Armsquick coupler
DrawbarCat. 4
 Cat. 5 OptOptional
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Engine RPM1000@1998 (early)
 1000@1811 (late)
Dimensions & Tires
Wheelbase154 inches
391 cm
Weight43855 lbs
19892 kg
Front tire710/70R42
Rear tire710/70R42
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps240
Batteries2
Battery CCA1000
Battery volts12
References
Steiger 540 references literature
Steiger 370-620 Tractors published in 2014, by CaseIH
