CaseIH PJN65
|
|
| Production | |
| Manufacturer | CaseIH |
| Orchard/Vineyard tractor | |
| CaseIH PJN65 Engine | |
| 4.0L 4-cyl diesel | |
| Fuel tank | 15.85 gal 60.0 L |
 Engine details ... | |
| CaseIH PJN65 Transmissions | |
| 12-speed synchromesh | |
| 24-speed | |
| 24-speed two-speed power shift | |
 Transmission details ... |
| CaseIH PJN65 Power | |
| Engine | 65 hp 48.5 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Steering | hydrostatic power |
| Four-post ROPS. Cab optional with air-conditioning. | |
| Photos | |
| No photos of the CaseIH PJN65 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Valves | 4 *Optional. |
| Pump flow | 10.41 gpm 39.4 lpm |
| 17 gpm*Optional dual pump. 64.3 lpm | |
| Steering flow | 5.2 gpm 19.7 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | top-link draft sensing |
| Rear lift (at ends) | 5291 lbs 2399 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Dimensions & Tires | |
| 2WD Wheelbase | 83.1 inches 211 cm |
| 4WD Wheelbase | 81.7 inches 207 cm |
| Weight | 5335 to 5710 pounds |
| Rear tire | 360/70R24 |
 Full dimensions and tires ... | |
| References | |
 | |
| PJ Series published in 2001, by CaseIH |
