CaseIH 685XL
|
|
| Production | |
| Manufacturer | CaseIH |
| Utility tractor | |
| Built in Doncaster, England | |
| CaseIH 685XL Engine | |
| CaseIH 3.9L 4-cyl diesel | |
| Fuel tank | 29.6 gal 112.0 L |
 Engine details ... | |
| CaseIH 685XL Transmissions | |
| 8-speed synchromesh | |
| 16-speed two-speed power shift | |
 Transmission details ... |
| CaseIH 685XL Power | |
| Engine | 69 hp 51.5 kW |
| PTO (claimed) | 64.2 hp 47.9 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Steering | hydrostatic power |
| Wet disc brakes | |
| Secura cab standard. | |
| Photos | |
| No photos of the CaseIH 685XL are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pressure | 2500 psi 172.4 bar |
| Pump flow | 12.4 gpm 46.9 lpm |
| Steering flow | 2.6 gpm 9.8 lpm |
| Steering press. | 1550 psi 106.9 bar |
| Tractor hitch | |
| Rear Type | II/I |
| Control | Top-link draft sensing. |
| Rear lift | 5250 lbs 2381 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic wet disc |
| Rear PTO Type | 540/1000 |
| Engine RPM | 540@2140 |
| 1000@2190 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 88.2 inches 224 cm |
| 4WD Wheelbase | 85.4 inches 216 cm |
| Weight | 6700 to 7200 pounds |
| Front tire | 10.00-16 |
| 2WD Rear tire | 16.9-34 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 45 |
| Battery CCA | 420 |
| Battery volts | 12 |
| Battery AH | 95 |
| References | |
 | |
| 85 Series published in 1985, by CaseIH |
