CaseIH 585XL
|
|
| Production | |
| Manufacturer | CaseIH |
| Utility tractor | |
| Built in Doncaster, England | |
| CaseIH 585XL Engine | |
| CaseIH 3.4L 4-cyl diesel | |
| Fuel tank | 29.6 gal 112.0 L |
 Engine details ... | |
| CaseIH 585XL Transmissions | |
| 8-speed synchromesh | |
| 16-speed two-speed power shift | |
 Transmission details ... |
| CaseIH 585XL Power | |
| Engine | 60 hp 44.7 kW |
| PTO (claimed) | 53.4 hp 39.8 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Steering | hydrostatic power |
| Wet disc brakes | |
| Secura cab standard. | |
| Photos | |
| No photos of the CaseIH 585XL are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pressure | 2500 psi 172.4 bar |
| Pump flow | 12.4 gpm 46.9 lpm |
| Steering flow | 2.6 gpm 9.8 lpm |
| Steering press. | 1500 psi 103.4 bar |
| Tractor hitch | |
| Rear Type | II/I |
| Control | Top link draft sensing. |
| Rear lift | 4400 lbs 1995 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic wet disc |
| Rear PTO Type | 540/1000 |
| Engine RPM | 540@2140 |
| 1000@2190 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 84.7 inches 215 cm |
| 4WD Wheelbase | 85 inches 215 cm |
| Weight | 6400 to 7200 pounds |
| Front tire | 7.50-18 |
| 2WD Rear tire | 13.6-38 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 45 |
| Battery CCA | 420 |
| Battery volts | 12 |
| Battery AH | 95 |
| References | |
 | |
| 85 Series published in 1985, by CaseIH |
