John Deere 7290R Engine


John Deere 7290R tractor photo
2014 -
7R Series
Row-Crop tractor
Series map:
7270R
7290R
7310R
201.3kw
216.3kw
231.2kw
Engine Detail
John Deere PowerTech PVX
variable geometry turbocharger diesel
6-cylinder 24-valve
liquid-cooled inline
Displacement549 ci
9.0 L
Bore/Stroke4.66x5.35 inches
118 x 136 mm
EmissionsStage IIIB
Emission controlcooled exhaust gas recirculation
Rated Power (net)278 hp
207.3 kW
Rated Power (gross)290 hp
216.3 kW
Maximum Power (net)310.1 hp
231.2 kW
Maximum Power (gross)323 hp
240.9 kW
Fuel systemelectronic high-pressure common rail
Compression16:1
Rated RPM2100
Operating RPM1550-2100
Torque962.5 lb-ft
1305.2 Nm
Torque RPM1600
Starterelectric
Starter volts12
Coolant capacity47 qts
44.5 L
Engine Oil
7290R diesel engine oil chart
Oil capacity28.5 qts
27.0 L
Oil change500 h
