New Holland T9.645


New Holland T9.645 tractor photo
2014 - 2023
T9 Series
Four-wheel Drive (4WD) tractor
Series map:
T9.600
T9.645
T9.700
535.0hp
580.0hp
620.0hp
Production
ManufacturerNew Holland (a part of CNH)
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA
Variants
T9.645wheeled
T9.645 SmartTraxcrawler
Steiger 580similar CaseIH model
New Holland T9.645 Engine
FPT 12.9L 6-cyl diesel
Fuel tank480 gal
1816.8 L
Exhaust fluid (DEF)66 gal
249.8 L
Engine details ...
New Holland T9.645 Power
Engine (gross)580 hp
432.5 kW
Engine (max)638 hp
475.8 kW
PTO (claimed)473 hp
352.7 kW
Drawbar (tested)495.25 hp
369.3 kW
PTO (tested)540.36 hp
402.9 kW
Performance test details ...
Mechanical
Four-wheel drive
Steeringhydrostatic power articulated
Wet disc brakes
Trailer brakeshydraulic OptOptional
Cab standard with air-condioning. Optional Comfort Ride cab suspension. ISOBUS compliant; Intelliview IV; IntelliSteer
Photos
No photos of the New Holland T9.645 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center load sensing (CCLS)
Valves4 to 8
Standard Pump flow42 gpm
159.0 lpm
High-Flow Pump flow57 gpm
215.7 lpm
MegaFlow Pump flow113 gpm
427.7 lpm
Tractor hitch
Rear TypeIVN OptOptional
Controlposition control
Rear lift (at 24"/610mm)19621 lbs
8900 kg
Rear Armsadjustable link ends
DrawbarCat. 4
 Cat. 5 OptOptional
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Engine RPM1000@1811
Dimensions & Tires
Wheelbase154 inches
391 cm
Weight44046 lbs
19979 kg
Front tire710/70
Rear tire710/70
Full dimensions and tires ...
T9.645 Serial Numbers
2014ZDFxxxxxx
2015ZEFxxxxxx
2016ZFFxxxxxx
2017ZGFxxxxxx
2018ZHFxxxxxx
2019ZJFxxxxxx
2020ZKFxxxxxx
2021ZLFxxxxxx

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps200
Batteries2
Battery CCA1000
Battery volts12
References
T9.645 references literature
T9 Series published in 2018, by New Holland
