UTB/Universal S640
|
|
| Production | |
| Manufacturer | UTB/Universal |
| Agricultural Crawler tractor | |
| Built in Brasov, Romania | |
| Variants | |
| S640 | standard |
| SM640 | wide-track |
| U640 | wheeled tractor |
| UTB/Universal S640 Engine | |
| UTB 3.6L 4-cyl diesel | |
| Fuel tank | 14.3 gal 54.1 L |
 Engine details ... | |
| UTB/Universal S640 Transmission | |
| 6-speed constant mesh | |
 Transmission details ... |
| UTB/Universal S640 Power | |
| Engine | 65 hp 48.5 kW |
| PTO (claimed) | 62 hp 46.2 kW |
| Mechanical | |
| Drive | crawler |
| Band brakes | |
| Open operator station. | |
| Photos | |
| No photos of the UTB/Universal S640 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2475 psi 170.7 bar |
| Pump flow | 5.8 gpm 22.0 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Rear lift | 2860 lbs 1297 kg |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 |
| Engine RPM | 540@1970 |
| Dimensions & Tracks | |
| Wheelbase | 60.2 inches 152 cm |
| Weight | 6700 lbs 3039 kg |
| 12.2-inch tracks | |
 Full dimensions and tracks ... | |
| UTB/Universal S640 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Loaders published in 1987, by Universal |
