John Deere 5115M



John Deere 5115M tractor photo
2012 - 2022
Model year
5M Series
Utility tractor
Series map:
5100M
5115M
100.0hp
115.0hp
Production
ManufacturerJohn Deere
Utility tractor
FactoriesAugusta, Georgia, USA
 Pune, India
Original price was $73,218 in 2021
John Deere 5115M Engine
John Deere 4.5L 4-cyl diesel
ROPS Fuel tank38 gal
143.8 L
Cab Fuel tank46 gal
174.1 L
Engine details ...
John Deere 5115M Transmissions
16-speed power shuttle
32-speed two-speed power shift
Transmission details ...
John Deere 5115M Power
Engine (gross)115 hp
85.8 kW
PTO (claimed)100 hp
74.6 kW
Drawbar (tested)76.34 hp
56.9 kW
PTO (tested)109.96 hp
82.0 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic
Power steering
Hydraulic wet disc brakes
Isolated open operator station with foldable two-post ROPS. Optional premium open station features extended fenders and integral work lights. Standard and premium cabs available with air-conditioning.
Photos
John Deere 5115M
John Deere 5115M photos...
Hydraulics
Typeopen center
Pump flow18.4 gpm
69.6 lpm
Total flow24.7 gpm
93.5 lpm
Tractor hitch
Rear TypeII/I
Controllower-link draft sensing
Rear lift (at 24"/610mm)5600 lbs
2540 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/540E
 540/540E/1000 OptOptional
Dimensions & Tires
Wheelbase92.5 inches
234 cm
Weight8000 to 8900 pounds
Front tire12.4R24
2WD Rear tire18.4R30
Full dimensions and tires ...
John Deere 5115M attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
5115M references literature
5M Series published in 2015, by John Deere
5M Series published in 2016, by John Deere
5M Series published in 2018, by John Deere*
Operator's Manual 5094M, 5090M, 5100M, 5100MH, 5100ML, 5115M and 5115ML (FT4) Tractors (OMSU54598) published in 2017
*Publication contains known errors.
