McCormick Intl X7.450
| | 2013 - |
| X7.4 Series | | Row-Crop tractor |
|
| Production |
| Manufacturer | McCormick Intl (a part of Argo)
|
| Row-Crop tractor |
| McCormick Intl X7.450 Power |
| Engine | 150 hp
111.9 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | electro-hydraulic front and rear
|
| Steering | hydrostatic power
|
| Wet disc brakes |
| Trailer brakes | hydraulic (optional)
|
| | pneumatic (optional)
|
| Cab standard with air-conditioning. Optional electro-hydraulic cab suspension. |
| Photos |
| No photos of the McCormick Intl X7.450 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | closed center
|
| Valves | 3 to 6
|
| Pump flow | 32.5 gpm
123.0 lpm
|
| Steering flow | 11.6 gpm
43.9 lpm
|
| Tractor hitch |
| Rear Type | III/IIIN
|
| Control | lower link draft sensing
|
| Rear lift | 20500 lbs
9298 kg
|
| Front Hitch | optional
|
| Front lift | 7716 lbs
3499 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic wet discs
|
| Rear PTO Type | 540/540E/1000/1000E (1.375)
|
| Front PTO | independent (optional)
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on June 18, 2014 |
