LS XU5055
| | 2013 - 2016 |
| XU Series | | Utility tractor |
|
Series map:
XU5055
XU5065
55.0hp
65.0hp
| Production |
| Manufacturer | LS
|
| Utility tractor |
| LS XU5055 Power |
| Engine (gross) | 55 hp
41.0 kW
|
| PTO (claimed) | 46.5 hp
34.7 kW
|
| Mechanical |
| Four-wheel drive |
| Steering | hydrostatic power
|
| Wet disc brakes |
| Two-post foldable ROPS. Cab optional with air-conditioning. |
| Photos |
| No photos of the LS XU5055 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pump flow | 10.5 gpm
39.7 lpm
|
| Total flow | 15.8 gpm
59.8 lpm
|
| Steering flow | 5.3 gpm
20.1 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | position and draft control
|
| Rear lift | 4079 lbs
1850 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 55
|
| Battery volts | 12
|
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on August 29, 2019 |
