LS U5020
| | 2009 - ???? |
| U Series | | Utility tractor |
|
Series map:
U5020
U5030
47.0hp
55.0hp
| Production |
| Manufacturer | LS
|
| Utility tractor |
| LS U5020 Power |
| Engine (gross) | 47 hp
35.0 kW
|
| PTO (claimed) | 42 hp
31.3 kW
|
| Mechanical |
| Four-wheel drive |
| Steering | hydrostatic power
|
| Wet disc brakes |
| Two-post foldable ROPS. Cab optional with air-conditioning. |
| Photos |
| No photos of the LS U5020 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pump flow | 9.6 gpm
36.3 lpm
|
| Total flow | 14.5 gpm
54.9 lpm
|
| Steering flow | 4.9 gpm
18.5 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position and draft control
|
| Rear lift | 4079 lbs
1850 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 50
|
| Battery volts | 12
|
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on May 30, 2014 |
