Tractors > John Deere > 5100E

John Deere 5100E



John Deere 5100E tractor photo
2013 - 2025
Model year
5E Series
Utility tractor
Series map:
5085E
5100E
85.0hp
100.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Augusta, Georgia, USA
Original price$46,110 (2014 ROPS )
$55,048 (2014 Cab )
John Deere 5100E Engine
John Deere 4.5L 4-cyl diesel
ROPS Fuel tank25 gal
94.6 L
Cab Fuel tank30 gal
113.6 L
Engine details ...
John Deere 5100E Transmission
12-speed partially synchronized
Transmission details ...
John Deere 5100E Power
Engine (gross)100 hp
74.6 kW
PTO (claimed)85 hp
63.4 kW
PTO (tested)89.49 hp
66.7 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Differential lockmechanical
Power steering
Hydraulic wet disc brakes
Two-post foldable ROPS. Cab optional.
Photos
No photos of the John Deere 5100E are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Rear valves0, 2 or 3
Mid valves0, 2 or 3
Pump flow15.9 gpm
60.2 lpm
Total flow22.5 gpm
85.2 lpm
Steering flow6.6 gpm
25.0 lpm
Tractor hitch
Rear TypeII
Controltop link draft sensing
Rear lift (at 24"/610mm)3213 lbs
1457 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/540E (1.375)
Engine RPM540@2400
 540E@1700
Dimensions & Tires
Wheelbase90.6 inches
230 cm
Weight7055 to 7937 pounds
Front tire12.4-24
Rear tire18.4-30
Full dimensions and tires ...
John Deere 5100E attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps90
 120 OptOptional
Battery volts12
References
5100E references literature
5D - 5E Utility Tractors published in 2013, by John Deere*
5D - 5E Utility Tractors published in 2014, by John Deere*
*Publication contains known errors.
