John Deere 5085E
| | 2013 - 2017 |
|
| 5E Series | | Utility tractor |
|
| Production |
| Manufacturer | John Deere
|
| Utility tractor |
| Built in Augusta, Georgia, USA |
| Original price | $41,102 (2014 ROPS )
|
| $50,040 (2014 Cab )
|
| John Deere 5085E Power |
| Engine (gross) | 85 hp
63.4 kW
|
| PTO (claimed) | 70 hp
52.2 kW
|
| Mechanical |
| Four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | mechanical
|
| Power steering |
| Hydraulic wet disc brakes |
| Two-post foldable ROPS. Cab optional. |
| Hydraulics |
| Type | open center
|
| Rear valves | 0, 2 or 3
|
| Mid valves | 0, 2 or 3
|
| Pump flow | 15.9 gpm
60.2 lpm
|
| Total flow | 22.5 gpm
85.2 lpm
|
| Steering flow | 6.6 gpm
25.0 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | top link draft sensing
|
| Rear lift (at 24"/610mm) | 3213 lbs
1457 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear PTO Type | 540/540E (1.375)
|
| Engine RPM | 540@2400
|
| | 540E@1700
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 90
|
| | 120 OptOptional
|
| Battery volts | 12
|
| References |
 |
| 5D - 5E Utility Tractors published in 2013, by John Deere* |
| 5D - 5E Utility Tractors published in 2014, by John Deere* |
| *Publication contains known errors. |
