CaseIH Magnum 340


CaseIH Magnum 340 tractor photo
2011 - 2025
Model year
Magnum Series
Row-Crop tractor
Series map:
Magnum 310
Magnum 340
Magnum 380
310.0hp
340.0hp
380.0hp
Production
ManufacturerCaseIH (a part of CNH)
Row-Crop tractor
Built in Racine, Wisconsin, USA
Original price$301,919 (2014 Power Shift )
$315,261 (2014 CVT )
Variants
T8.410similar New Holland model
CaseIH Magnum 340 Engine
FPT 8.7L 6-cyl diesel
Fuel tank179 gal (power shift)
677.5 L
 163 gal (CVT)
617.0 L
Exhaust fluid (DEF)26 gal
98.4 L
Engine details ...
CaseIH Magnum 340 Transmissions
19-speed full power shift
18-speed full power shift
continuously variable transmission (CVT)
Transmission details ...
CaseIH Magnum 340 Power
Engine (gross)340 hp
253.5 kW
Engine (max)375 hp
279.6 kW
PTO (claimed)290 hp
216.3 kW
Drawbar (tested)259.32 hp
193.4 kW
PTO (tested)336.17 hp
250.7 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Power steering
Wet disc  brakes
Cab standard with air-conditioning. AFS ready
Photos
No photos of the CaseIH Magnum 340 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typevariable displacement pressure-flow compensating   (PFC)
Valves4 to 6
Pump flow44 gpm
166.5 lpm
 59 gpm (optional)
223.3 lpm
 75 gpm (optional)
283.9 lpm
Tractor hitch
Rear TypeIII/IVN
 III/IIIN (optional)
Controlelectronic lower link draft sensing
Rear lift (at 24"/610mm)17500 lbs
7938 kg
 19500 lbs (optional)
8845 kg
Rear ArmsAdjustable quick coupler
DrawbarCat. 4
 Cat. 3 (optional)
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
 540/1000 (1.375)OptOptional
Engine RPM540@1800
 1000@1800
Dimensions & Tires
Wheelbase120 inches
304 cm
 122 inches (CVT)
309 cm
Weight29600 lbs
13426 kg
Front tire420/8R34
Rear tire480/80R50 (duals )
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps200
Batteries2
Battery volts12
References
Magnum 340 references literature
Magnum 180-380 Tractors published in 2014, by CaseIH
Magnum 250-380 HP Tractors published in 2016, by CaseIH
Magnum Series Tractors published in 2019, by CaseIH
