Massey Ferguson 360
| | 1987 - 1991 |
|
| 300 Series | | Utility tractor |
|
Series map:
360
375
57.0hp
67.0hp
| Production |
| Manufacturer | Massey Ferguson
|
| Utility tractor |
| Built in Coventry, England |
| Original price | $18,000 (1988 2WD )
|
| $25,000 (1988 4WD )
|
| Massey Ferguson 360 Power |
| Engine | 57 hp
42.5 kW
|
| PTO (claimed) | 51 hp
38.0 kW
|
| Drawbar (tested) | 37.4 hp
27.9 kW
|
| PTO (tested) | 49.2 hp
36.7 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Final drives | planetary
|
| Power steering |
| Wet disc brakes |
| Two-post ROPS. Canopy optional. |
| Hydraulics |
| Type | open center
|
| Pressure | 3000 psi
206.8 bar
|
| Pump flow | 9.2 gpm (aux pump)
34.8 lpm
|
| | 4.5 gpm (hitch)
17.0 lpm
|
| Total flow | 13.7 gpm
51.9 lpm
|
| Tractor hitch |
| Rear Type | II/I
|
| Control | position and draft control
|
| Rear lift | 3890 lbs*Capacity through full lift range
1764 kg
|
| Rear lift (at ends) | 4729 lbs*Capacity with links horizontal
2145 kg
|
| Power Take-off (PTO) |
| Rear PTO | live
|
| | independent OptOptional
|
| Rear PTO Type | 540 (1.375)
|
| 360 Serial Number Location |
 |
| Serial number plate on the right side of the tractor, near the brake pedals. |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 45
|
| Battery CCA | 420
|
| Battery volts | 12
|
| References |
 |
| 300 published in 1986, by Massey Ferguson |
| 300 published in 1986, by Massey Ferguson |
| 300 Series Tractors Data Book published in 1992, by Massey Ferguson |
| M-F 300 Series Tractor Workshop Manual (1449 244M1) published in 1991 |
