Tractors > Wagner > WA-14

Wagner WA-14



Wagner WA-14 tractor photo
1961 - 1969
WA Series
Four-wheel Drive (4WD) tractor
Series map:
WA-9
WA-14
WA-17
160.0hp
220.0hp
250.0hp
Production
ManufacturerWagner
Four-wheel Drive (4WD) tractor
Built in Portland, Oregon, USA
Wagner WA-14 Engine
Cummins 12.2L 6-cyl diesel
Engine details ...
Wagner WA-14 Transmission
10-speed
Transmission details ...
Wagner WA-14 Power
Engine220 hp
164.1 kW
Mechanical
Four-wheel drive
Final drivesplanetary
Steeringhydraulic power
Pneumatic brakes
Open operator station. Cab optional.
Photos
Wagner WA-14
Wagner WA-14 photos...
Capacity
Fuel150 gal
567.8 L
Hydraulic system80 gal
302.8 L
Hydraulics
Capacity80 gal
302.8 L
Pump flow63 gpm
238.5 lpm
Dimensions & Tires
Wheelbase136 inches
345 cm
Weight23000 lbs
10432 kg
Front tire18-26
Rear tire18-26
Full dimensions and tires ...
