Mahindra Max 24
|
|
| Production | |
| Distributor | Mahindra |
| Manufacturer | Mitsubishi |
| Compact Utility tractor | |
| Mahindra Max 24 Engine | |
| Mitsubishi 1.3L 3-cyl diesel | |
| Fuel tank | 6.1 gal 23.1 L |
 Engine details ... | |
| Mahindra Max 24 Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mahindra Max 24 Power | |
| Engine | 24.4 hp 18.2 kW |
| PTO (claimed) | 19.5 hp 14.5 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. |
| Photos | |
 | |
 Mahindra Max 24 photos... | |
| Hydraulics | |
| Type | open center |
| Rear valves | 1 OptOptional |
| Pump flow | 4.6 gpm 17.4 lpm |
| Steering flow | 2.7 gpm 10.2 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift | 1400 lbs 635 kg |
| Power Take-off (PTO) | |
| Rear PTO | live |
| Rear PTO Type | 540 |
| Engine RPM | 540@2376 |
| Mid PTO Type | 2000 |
| Engine RPM | 2000@2556 |
| Dimensions & Tires | |
| Weight | 1693 lbs 767 kg |
| Front tire | 6x12 |
| Rear tire | 9.5x16 |
 Full dimensions and tires ... | |
| Mahindra Max 24 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 50 |
| Battery volts | 12 |
| Battery AH | 46 |
| References | |
 | |
| Max Series - Tier IV published in 2014, by Mahindra | |
| Max Series published in 2017, by Mahindra |
