CaseIH Puma 200
| | 2011 - 2025 |
|
| Puma Series | | Row-Crop tractor |
|
| Production |
| Manufacturer | CaseIH
|
| Row-Crop tractor |
| Built in Basildon, England |
| Original price | $198,831 (2015 CVT )
|
| $186,751 (2015 power shift )
|
| CaseIH Puma 200 Power |
| Engine | 200 hp
149.1 kW
|
| PTO (claimed) | 175 hp
130.5 kW
|
| Drawbar (tested) | 140.7 hp
104.9 kW
|
| PTO (tested) | 191.4 hp
142.7 kW
|
 Performance test details ... |
| Mechanical |
| Four-wheel drive |
| Power steering |
| Wet disc brakes |
| Trailer brakes | hydraulic OptOptional
|
| | pneumatic OptOptional
|
| Cab standard with air-conditioning. |
| Photos |
| No photos of the CaseIH Puma 200 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | closed center pressure flow compensating
|
| Valves | 3 to 5
|
| Pump flow | 30 gpm
113.6 lpm
|
| | 39.6 gpmOptOptional
149.9 lpm
|
| Total flow | 47 gpm
177.9 lpm
|
| | 56.6 gpmOptOptional
214.2 lpm
|
| Steering flow | 17 gpm
64.3 lpm
|
| Tractor hitch |
| Rear Type | II/IIIN
|
| Rear lift | 12787 lbs
5800 kg
|
| | 15000 lbsOptOptional
6804 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 1000 (1.375)
|
| | 1000/1000E (1.75)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 150
|
| Battery volts | 12
|
| References |
 |
| Puma 185-240 Tractors published in 2021, by CaseIH |
| Puma Series Tractors published in 2017, by CaseIH |
