Tractors > CaseIH > Magnum 220

CaseIH Magnum 220 Transmission



CaseIH Magnum 220 tractor photo
2014 - 2025
Model year
Magnum Series
Row-Crop tractor
Series map:
Magnum 200
Magnum 220
Magnum 240
200.0hp
220.0hp
240.0hp
Transmission options
19-speed full power shift
continuously variable transmission (CVT)
Transmission
Typefull power shift
Gears19 forward and 6 reverse
Clutchelectro-hydraulic wet disc
Speeds
Magnum 220 full power shift speeds
Transmission
Typecontinuously variable transmission (CVT)
Gearsinfinite forward and reverse
