CaseIH Magnum 210
|
|
| Production | |
| Manufacturer | CaseIH |
| Row-Crop tractor | |
| Built in Racine, Wisconsin, USA | |
| CaseIH Magnum 210 Engine | |
| FPT 6.7L 6-cyl diesel | |
 Engine details ... |
| CaseIH Magnum 210 Transmissions | |
| 18-speed full power shift | |
| 19-speed full power shift | |
| continuously variable transmission (CVT) | |
 Transmission details ... |
| CaseIH Magnum 210 Power | |
| Engine (gross) | 215 hp 160.3 kW |
| Engine (max) | 260 hp 193.9 kW |
| PTO (claimed) | 180 hp 134.2 kW |
| Drawbar (tested) | 174.51 hp 130.1 kW |
| PTO (tested) | 214.60 hp 160.0 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary |
| Steering | hydrostatic power |
| Hydraulic wet disc brakes | |
| Magnum cab standard with air-conditioning. Optional cab suspension. | |
| Photos | |
| No photos of the CaseIH Magnum 210 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 105 gal 397.4 L |
| Exhaust fluid (DEF) | 15 gal 56.8 L |
| Hydraulic system | 26.5 gal 100.3 L |
| Hydraulics | |
| Type | pressure flow compensating |
| Capacity | 26.5 gal 100.3 L |
| Rear valves | 3 to 5 |
| Mid valves | 2 or 3 (optional) |
| Pump flow | 35 gpm 132.5 lpm |
| 43 gpm (CVT) 162.8 lpm | |
| Tractor hitch | |
| Rear Type | III/IIIN |
| Control | electronic lower link draft sensing |
| Rear lift (at 24"/610mm) | 10200 lbs 4626 kg |
| 14100 lbs (optional) 6395 kg | |
| Drawbar | Cat. 3 swinging drawbar |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| 1000 (1.75) | |
| Dimensions & Tires | |
| Wheelbase | 118.3 inches 300 cm |
| Weight | 21500 lbs 9752 kg |
| Front tire | 380/85R34 |
| Rear tire | 480/80R46 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 150 |
| 200 (optional) | |
| Battery volts | 12 |
