John Deere 4044R
| | 2014 - |
| 4R Series | | Compact Utility tractor |
|
Series map:
4044R
4049R
43.1hp
49.0hp
| Production |
| Manufacturer | John Deere
|
| Compact Utility tractor |
| Built in Augusta, Georgia, USA |
| John Deere 4044R Power |
| Engine (gross) | 43.1 hp
32.1 kW
|
| Gear PTO (claimed) | 34.6 hp
25.8 kW
|
| Hydro PTO (claimed) | 33.6 hp
25.1 kW
|
| Mechanical |
| Four-wheel drive |
| Final drives | planetary
|
| Differential lock | mechanical rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Two-post folding ROPS. Cab optional with air-conditioning. |
| Hydraulics |
| Type | open center
|
| Valves | 3 to 5
|
| Total flow | 15.9 gpm
60.2 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| Rear lift (at ends) | 3130 lbs
1419 kg
|
| Rear lift (at 24"/610mm) | 2500 lbs
1134 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2400
|
| | 540E@1750
|
| 4044R Serial Number Location |
 |
| Serial number plate on the right side of the 4044R tractor frame, above the front axle. |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 75
|
| Battery CCA | 770
|
| Battery volts | 12
|
| References |
 |
| 4 Family published in 2015, by John Deere |
| 4 Family published in 2017, by John Deere |
| 4 Series published in 2020, by John Deere |
| 4 Series published in 2023, by John Deere |
| Operator's Manual 4 Series (OMTR130411) published in 2023* |
| *Publication contains known errors. |
