John Deere 6150RH
2013 - 2014
6R Series High-Clearance tractor
Series map:
6150RH
150.0hp
Production
Manufacturer John Deere
High-Clearance tractor
Original price was $145,664 in 2014
John Deere 6150RH Power
Engine (gross) 150 hp111.9 kW
Engine (max) 165 hp123.0 kW
PTO (claimed) 120 hp89.5 kW
Mechanical
Four-wheel drive
Cab standard with air-conditioning.
Photos
No photos of the John Deere 6150RH are currently available. To submit yours, email it to Peter@TractorData.com . Photos may only be used with the permission of the original photographer.
Hydraulics
Type closed center pressure and flow compensated
Pump flow 30.1 gpm113.9 lpm
SCV flow 26.4 gpm99.9 lpm
Tractor hitch
Rear Type III/IIIN
Rear lift 9193 lbs4169 kg
Drawbar Cat. 2
Electrical
Ground negative
Charging system alternator
Charging amps 120
Battery volts 12
References
Operator's Manual Tractors 6140R, 6150R, 6150RH, 6170R, 6190R and 6120R (OMAL211531) published in 2014
Specialty Tractors published in 2014, by John Deere
