John Deere 6140D
| | 2008 - 2016 |
|
| 6D Series | | Utility tractor |
|
Series map:
6130D
6140D
130.0hp
140.0hp
| Production |
| Manufacturer | John Deere
|
| Utility tractor |
| Built in Saltillo, Mexico |
| Original price was $76,721 |
| Mechanical |
| Four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | mechanical rear
|
| | limited-slip front differential
|
| Power steering |
| Hydraulic wet disc brakes |
| Cab with air-conditioning. |
| Hydraulics |
| Type | open center
|
| Pressure | 2828 psi
195.0 bar
|
| Valves | 2 or 3
|
| Pump flow | 20 gpm
75.7 lpm
|
| SCV flow | 20 gpm
75.7 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | position control
|
| | draft-control optional
|
| Rear lift (at 24"/610mm) | 5500 lbs
2494 kg
|
| | 7300 lbs (optional)
3311 kg
|
| Drawbar | Cat. II
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000 (1.375)
|
| Engine RPM | 540@2085
|
| | 1000@2067
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
