Kioti NX5010
|
|
| Production | |
| Manufacturer | Kioti (a part of Daedong) |
| Compact Utility tractor | |
| Kioti NX5010 Engine | |
| Daedong 1.8L 3-cyl diesel | |
| Fuel tank | 14.8 gal 56.0 L |
 Engine details ... | |
| Kioti NX5010 Transmissions | |
| 24-speed synchro shuttle | |
| hydrostatic | |
 Transmission details ... |
| Kioti NX5010 Power | |
| Engine (gross) | 50 hp 37.3 kW |
| Gear PTO (claimed) | 41.8 hp 31.2 kW |
| Hydro PTO (claimed) | 38.9 hp 29.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Wet discs brakes | |
| Two-post foldable ROPS. Cab optional with air-conditioning. | |
| Photos | |
 | |
 Kioti NX5010 photos... | |
| Hydraulics | |
| Type | open center |
| Valves | 0 to 2 |
| Gear Pump flow | 16.5 gpm 62.5 lpm |
| Hydro Pump flow | 17.9 gpm 67.8 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position and draft control |
| Rear lift (at 24"/610mm) | 3177 lbs 1441 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Mid PTO | optional |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 75.6 inches 192 cm |
| Weight | 4068 to 4548 pounds |
| Front tire | 8-16 |
| Rear tire | 13.6-24 |
 Full dimensions and tires ... | |
| Kioti NX5010 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| NX Series published in 2018, by Kitoi |
