Challenger MT875E
| | 2014 - 2020 |
| MT800E Series | | Agricultural Crawler tractor |
|
Series map:
MT865E
MT875E
540.0hp
590.0hp
| Production |
| Manufacturer | Challenger (a part of AGCO)
|
| Agricultural Crawler tractor |
| Built in Jackson, Minnesota, USA |
| Challenger MT875E Power |
| Engine (gross) | 590 hp
440.0 kW
|
| PTO (claimed) | 425 hp
316.9 kW
|
| Drawbar (tested) | 445.03 hp
331.9 kW
|
| PTO (tested) | 561.47 hp
418.7 kW
|
 Performance test details ... |
| Mechanical |
| Drive | crawler
|
| Steering | power differential
|
| Cab standard with air-conditioning. |
| Hydraulics |
| Type | closed center pressure flow compensated
|
| Pressure | 2900 psi
200.0 bar
|
| Valves | 4 to 6
|
| Pump flow | 58.1 gpm
219.9 lpm
|
| | 85 gpm (optional)
321.7 lpm
|
| SCV flow | 26.4 gpm
99.9 lpm
|
| | 36 gpm (optional)
136.3 lpm
|
| Tractor hitch |
| Rear lift | 19500 lbs
8845 kg
|
| Drawbar | Cat. 4
|
| | Cat. 5
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electronic
|
| Rear PTO Type | 1000 (1.75)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 300 (2x 150)
|
| Batteries | 4
|
| Battery CCA | 1000
|
| Battery volts | 12
|
| References |
 |
| MT700E & MT800E Series Challenger Track Tractors published in 2015, by AGCO |
| Challenger MT800E Series Tractors published in 2013, by AGCO |
| MT800E Series Tractors published in 2017, by AGCO |
| Challenger X-Edition published in 2015, by AGCO |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on October 20, 2022 |
