Tractors > Challenger > MT855E

Challenger MT855E



Challenger MT855E tractor photo
2014 - 2020
MT800E Series
Agricultural Crawler tractor
Series map:
MT845E
MT855E
MT865E
450.0hp
490.0hp
540.0hp
Production
ManufacturerChallenger (a part of AGCO)
Agricultural Crawler tractor
Built in Jackson, Minnesota, USA
Challenger MT855E Engine
AGCO Power 16.8L 12-cyl diesel
Fuel tank330 gal
1249.0 L
Exhaust fluid (DEF)30.5 gal
115.4 L
Engine details ...
Challenger MT855E Transmission
16-speed full power shift
Transmission details ...
Challenger MT855E Power
Engine (gross)490 hp
365.4 kW
PTO (claimed)400 hp
298.3 kW
Drawbar (tested)360.27 hp
268.7 kW
PTO (tested)453.59 hp
338.2 kW
Performance test details ...
Mechanical
Drivecrawler
Steeringpower differential
Cab standard with air-conditioning.
Photos
No photos of the Challenger MT855E are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center pressure flow compensated
Pressure2900 psi
200.0 bar
Valves4 to 6
Pump flow58.1 gpm
219.9 lpm
 85 gpm (optional)
321.7 lpm
SCV flow26.4 gpm
99.9 lpm
 36 gpm (optional)
136.3 lpm
Tractor hitch
Rear lift19500 lbs
8845 kg
DrawbarCat. 4
 Cat. 5
Power Take-off (PTO)
Rear PTOindependent
Clutchelectronic
Rear PTO Type1000 (1.75)
Dimensions & Tracks
Weight42596 lbs
19321 kg
18-inch tracks
Full dimensions and tracks ...
Electrical
Groundnegative
Charging systemalternator
Charging amps300 (2x 150)
Batteries4
Battery CCA1000
Battery volts12
References
MT855E references literature
MT700E & MT800E Series Challenger Track Tractors published in 2015, by AGCO
Challenger MT800E Series Tractors published in 2013, by AGCO
MT800E Series Tractors published in 2017, by AGCO
Challenger X-Edition published in 2015, by AGCO
