John Deere 3039R


John Deere 3039R tractor photo
2014 -
3R Series
Compact Utility tractor
Series map:
3033R
3039R
3046R
31.8hp
38.2hp
44.7hp
Production
ManufacturerJohn Deere
Compact Utility tractor
Built in Augusta, Georgia, USA
Original price was $27,222 in 2020
John Deere 3039R Power
Engine38.2 hp
28.5 kW
Shuttle PTO (claimed)31.6 hp
23.6 kW
Hydro PTO (claimed)31.1 hp
23.2 kW
Mechanical
Four-wheel drive
Final driveshelical gear
Power steering
Wet disc brakes
Two-post foldable ROPS. Optional cab with air-conditioning.
Capacity
Fuel11.8 gal (Cab)
44.7 L
 13.5 gal (ROPS)
51.1 L
Hydraulic system6.8 gal
25.7 L
Front axle5.1 qts
4.8 L
Hydraulics
Typeopen center
Capacity6.8 gal
25.7 L
Pump flow8.6 gpm
32.6 lpm
Total flow13.9 gpm
52.6 lpm
Steering flow5.3 gpm
20.1 lpm
Tractor hitch
Rear TypeI
Controlposition control
Rear lift (at ends)2530 lbs
1147 kg
Rear lift (at 24"/610mm)2200 lbs
997 kg
Front Hitch0
Front lift (at ends)1300 lbs
589 kg
Front lift (at 24"/610mm)815 lbs
369 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540 (1.375)
Mid PTOindependent OptOptional
Clutchelectro-hydraulic
Mid PTO Type2100
Dimensions & Tires
Wheelbase68 inches
172 cm
Weight2900 to 3570 pounds
Front tire7.00-14
Rear tire11.2-24
Full dimensions and tires ...
John Deere 3039R attachments
60.9" mid-mount mower deck
72.8" mid-mount mower deck
front-end loader
backhoe
Attachment details ...
3039R Serial Numbers
Location:Serial number plate on right side of tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
3039R references literature
3 Family published in 2015, by John Deere
3 Family published in 2017, by John Deere
3 Series published in 2019, by John Deere
3 Series published in 2022, by John Deere
