Challenger MT775E
| | 2014 - 2017 |
| MT700E Series | | Agricultural Crawler tractor |
|
Series map:
MT765E
MT775E
375.0hp
400.0hp
| Production |
| Manufacturer | Challenger (a part of AGCO)
|
| Agricultural Crawler tractor |
| Built in Jackson, Minnesota, USA |
| Challenger MT775E Power |
| Engine (gross) | 400 hp
298.3 kW
|
| Drawbar (tested) | 297.83 hp
222.1 kW
|
| PTO (tested) | 374.43 hp
279.2 kW
|
 Performance test details ... |
| Mechanical |
| Drive | crawler
|
| Steering | electro-hydraulic differential
|
| Hydraulic wet disc brakes |
| Cab standard. |
| Hydraulics |
| Pressure | 2900 psi
200.0 bar
|
| Valves | 4 to 6
|
| Pump flow | 58.1 gpm
219.9 lpm
|
| | 85 gpmOptOptional
321.7 lpm
|
| SCV flow | 26.4 gpm
99.9 lpm
|
| | 36 gpmOptOptional
136.3 lpm
|
| Tractor hitch |
| Rear Type | IVN/III
|
| Rear lift | 16000 lbs
7257 kg
|
| Drawbar | Cat. 4 standard
|
| | Cat. 3 optional
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 1000 (1.75)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 300 (2x 150amp)
|
| Batteries | 2
|
| Battery volts | 12
|
| References |
 |
| MT700E & MT800E Series Challenger Track Tractors published in 2015, by AGCO |
| MT700E Series published in 2013, by AGCO |
| Challenger X-Edition published in 2015, by AGCO |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on October 20, 2022 |
