Massey Ferguson 7615
|
|
| Production | |
| Manufacturer | Massey Ferguson (a part of AGCO) |
| Row-Crop tractor | |
| Built in Beauvais, France | |
| Massey Ferguson 7615 Engine | |
| Sisu 6.6L 6-cyl diesel | |
 Engine details ... |
| Massey Ferguson 7615 Transmissions | |
| 16-speed four-speed power shift | |
| 24-speed six-speed power shift | |
| continuously-variable transmission (CVT) | |
 Transmission details ... |
| Massey Ferguson 7615 Power | |
| Engine (net) | 140 hp 104.4 kW |
| PTO (claimed) | 110 hp 82.0 kW |
| 120 hp (Dyna-4) 89.5 kW | |
| Drawbar (tested) | 106.6 hp 79.5 kW |
| PTO (tested) | 141.9 hp 105.8 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary |
| Differential lock | electro-hydraulic standard |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic (optional) |
| pneumatic (optional) | |
| Cab standard. Optional hydraulic OptiRide cab suspension. AGCOCOMMAND (optional); Auto-Guide 3000 (optional) | |
| Capacity | |
| Fuel | 82 gal 310.4 L |
| Exhaust fluid (DEF) | 8 gal 30.3 L |
| Hydraulic system | 26.4 gal 99.9 L |
| Hydraulics | |
| Type | closed-center load sensing (CCLS) |
| open center OptOptional | |
| Capacity | 26.4 gal 99.9 L |
| Pressure | 2900 psi 200.0 bar |
| Valves | 3 (mechanical) |
| 4 (2 mech, 2 elec) | |
| 4 (electric) | |
| SCV flow | 24.3 gpm 92.0 lpm |
| Total flow | 29 gpm 109.8 lpm |
| Tractor hitch | |
| Control | electronic lower link draft sensing |
| Rear lift (at ends) | 9800 lbs 4445 kg |
| 11500 lbs (Dyna-VT) 5216 kg | |
| Front Hitch | optional |
| Drawbar | Cat. II with drop pin |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540/1000 (1.375) |
| 540/540E/1000 (1.375) | |
| 540/540E/1000/1000E (1.375) | |
| Engine RPM | 540@1890 |
| 540@2065 (Dyna-VT) | |
| 540E@1533 | |
| 540E@1590 (Dyna-VT) | |
| 1000@2030 | |
| 1000@2034 (Dyna-VT) | |
| 1000E@1572 | |
| Dimensions & Tires | |
| Wheelbase | 113.1 inches 287 cm |
| Weight | 15060 lbs 6831 kg |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 120 |
| 175 (option) | |
| 240 (dual 120 option) | |
| Batteries | 2 |
| Battery volts | 12 |
| References | |
 | |
| 7600 Series published in 2013, by Massey Ferguson |
