Massey Ferguson 1754
| | 2013 - 2018 |
| 1700 Series | | Compact Utility tractor |
|
Series map:
1749
1754
1758
48.3hp
53.6hp
59.0hp
| Production |
| Manufacturer | Massey Ferguson
|
| Compact Utility tractor |
| Original price was $32,788 in 2018 with shuttle, ROPS |
| Massey Ferguson 1754 Power |
| Engine | 53.6 hp
40.0 kW
|
| PTO (claimed) | 42.1 hp
31.4 kW
|
| Mechanical |
| Four-wheel drive |
| Final drives | bull gear
|
| Power steering |
| Wet disc brakes |
| Two-post folding ROPS. Cab optional with air-conditioning. |
| Hydraulics |
| Type | open center gear pump
|
| Valves | 1 to 3
|
| SCV flow | 11.6 gpm
43.9 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| | draft control OptOptional
|
| Rear lift (at 24"/610mm) | 3086 lbs
1399 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear PTO Type | 540 (1.375)
|
| Mid PTO | optional
|
| Mid PTO Type | 2000
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
