Kubota L6060
| | 2013 - |
| L60 Series | | Compact Utility tractor |
|
Series map:
L5460
L6060
56.0hp
62.0hp
| Production |
| Manufacturer | Kubota
|
| Compact Utility tractor |
| Variants |
| L6060HST | ROPS
|
| L6060HSTC | cab
|
| Kubota L6060 Power |
| Engine (gross) | 62 hp
46.2 kW
|
| Engine (net) | 60 hp
44.7 kW
|
| PTO (claimed) | 53 hp
39.5 kW
|
| Mechanical |
| Four-wheel drive |
| Steering | hydrostatic power
|
| Wet disc brakes |
| Two-post foldable ROPS. Grand Cab with air-conditioning optional. |
| Hydraulics |
| Pump flow | 9.4 gpm
35.6 lpm
|
| Total flow | 14.1 gpm
53.4 lpm
|
| Steering flow | 4.7 gpm
17.8 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control, draft control optional
|
| Rear lift (at 24"/610mm) | 2976 lbs
1349 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Mid PTO | optional
|
| Mid PTO Type | 2000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| ROPS Charging amps | 45
|
| Cab Charging amps | 60
|
| Battery volts | 12
|
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on February 28, 2021 |
