Kubota L5460
| | 2013 - |
| L60 Series | | Compact Utility tractor |
|
| Production |
| Manufacturer | Kubota
|
| Compact Utility tractor |
| Variants |
| L5460HST | ROPS
|
| L5460HSTC | cab
|
| Kubota L5460 Power |
| Engine (gross) | 56 hp
41.8 kW
|
| Engine (net) | 54 hp
40.3 kW
|
| PTO (claimed) | 46.5 hp
34.7 kW
|
| Mechanical |
| Four-wheel drive |
| Steering | hydrostatic power
|
| Wet disc brakes |
| Two-post foldable ROPS. Grand Cab with air-conditioning optional. |
| Photos |
| No photos of the Kubota L5460 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pump flow | 9.4 gpm
35.6 lpm
|
| Total flow | 14.1 gpm
53.4 lpm
|
| Steering flow | 4.7 gpm
17.8 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control, draft control optional
|
| Rear lift (at 24"/610mm) | 2976 lbs
1349 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Mid PTO | optional
|
| Mid PTO Type | 2000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| ROPS Charging amps | 45
|
| Cab Charging amps | 60
|
| Battery volts | 12
|
