John Deere 8320R Tests


John Deere 8320R tractor photo
2014 - 2019
8R Series
Row-Crop tractor
Series map:
8295R
8320R
8345R
295.0hp
320.0hp
345.0hp
OCED Tractor Test 2101
8320R fuel use from test 966
OCED Tractor Test 2101
Diesel 16-speed 4WD
October 23 - 31, 2014
Link: OCED Tractor Test 2101 file
PTO performance
Max power318.08 hp
237.2 kW
Power at rated engine speed281.25 hp
209.7 kW
Fuel use14.8 gal/hour
56.0 l/hour
Power at rated PTO speed307.69 hp
229.4 kW
Fuel use16.0 gal/hour
60.6 l/hour
Drawbar performance
Max power253.13 hp
188.8 kW
Fuel use14.8 gal/hour
56.0 l/hour
Gear 8 used for power test.
Max pull27922 lbs
12665 kg
Gear 5 used for pull test.
