CaseIH Farmall 85C
|
|
| Production | |
| Manufacturer | CaseIH |
| Utility tractor | |
| CaseIH Farmall 85C Engine | |
| Fiat Powertrain Technologies (FPT) 3.4L 4-cyl diesel | |
| Fuel tank | 30.3 gal 114.7 L |
 Engine details ... | |
| CaseIH Farmall 85C Transmissions | |
| 12-speed mechanical shuttle | |
| 12-speed power shuttle | |
| 20-speed creeper | |
 Transmission details ... |
| CaseIH Farmall 85C Power | |
| Engine | 84 hp 62.6 kW |
| PTO (claimed) | 70 hp 52.2 kW |
| Drawbar (tested) | 59.6 hp 44.4 kW |
| PTO (tested) | 76.6 hp 57.1 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | inboard planetary |
| Differential lock | mechanical rear |
| Steering | hydrostatic power |
| ROPS Brakes | mechanical wet disc |
| Cab Brakes | hydraulic wet disc |
| Two-post foldable ROPS. Cab optional with heat and air-conditioning. | |
| Photos | |
 | |
 CaseIH Farmall 85C photos... | |
| Hydraulics | |
| Type | open center |
| Valves | 1 or 2 |
| Pump flow | 12.9 gpm 48.8 lpm |
| 16.9 gpmOptOptional 64.0 lpm | |
| Tractor hitch | |
| Rear Type | II |
| Control | mechanical upper-link draft sensing |
| Rear lift (at 24"/610mm) | 5620 lbs 2549 kg |
| Drawbar | swinging drawbar |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| 540/1000 OptOptional | |
| Dimensions & Tires | |
| 4WD Wheelbase | 89 inches 226 cm |
| Weight | 7937 lbs 3600 kg |
| Rear tire | 16.9R34 |
 Full dimensions and tires ... | |
| CaseIH Farmall 85C attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 120 |
| ROPS Battery CCA | 730 |
| Cab Battery CCA | 800 |
| Battery volts | 121 |
| References | |
 | |
| Farmall C Series Tractors published in 2013, by CaseIH |
