New Holland T6050 Plus
|
|
| Production | |
| Manufacturer | New Holland |
| Utility tractor | |
| Variants | |
| T6050 Delta | economy |
| T6050 Plus | mid-level |
| T6050 Elite | premium |
| New Holland T6050 Plus Engine | |
| FPT 6.7L 6-cyl diesel | |
 Engine details ... |
| New Holland T6050 Plus Transmission | |
| 16-speed partial power shift | |
 Transmission details ... |
| New Holland T6050 Plus Power | |
| Engine (gross) | 125 hp 93.2 kW |
| PTO (claimed) | 105 hp 78.3 kW |
| Drawbar (tested) | 99.9 hp 74.5 kW |
| PTO (tested) | 116.5 hp 86.9 kW |
 Performance test details ... | |
| Mechanical | |
| Drive | 4x2 2WD |
| 4x4 MFWD 4WD (optional) | |
| Steering | hydrostatic power |
| SuperSteer optional | |
| Hydraulic wet disc brakes | |
| Horizon cab standard. | |
| Capacity | |
| Fuel | 66 gal 249.8 L |
| SuperSteer Fuel | 60.8 gal 230.1 L |
| Hydraulic system | 16.3 gal 61.7 L |
| Hydraulics | |
| Type | closed center load-sensing |
| Capacity | 16.3 gal 61.7 L |
| Valves | 2 to 4 |
| Pump flow | 26.5 gpm 100.3 lpm |
| Total flow | 37 gpm 140.0 lpm |
| Steering flow | 10.5 gpm 39.7 lpm |
| Tractor hitch | |
| Rear Type | II (mech) |
| II/IIIN (elec) | |
| Control | mechanical lower link draft sensing, electronic optional |
| Rear lift | 9285 lbs 4211 kg |
| 9620 lbs (optional) 4363 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| 2WD Wheelbase | 104.4 inches 265 cm |
| 4WD Wheelbase | 104.7 inches 265 cm |
| Weight | 10890 to 11336 pounds |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 120 |
| Charging volts | 12 |
| Battery CCA | 960 |
| Battery volts | 12 |
