Tractors > John Deere > 4520

John Deere 4520



John Deere 4520 tractor photo
2005 - 2014
Model year
4000 Twenty Compact Series
Compact Utility tractor
Series map:
4520
4720
60.0hp
66.0hp
Production
ManufacturerJohn Deere
Compact Utility tractor
Built in Augusta, Georgia, USA
Original price was $34,458 in 2013
The John Deere 4520 was upgraded for the 2009 model year (tractor serial number 650001) with an increase in engine power, optional 540e PTO, and eThrottle with the hydrostatic drive. During Nebraska testing, the John Deere 4720 was unable to produce the advertised 12 GPM hydraulic flow rate, actual flow was 11.3 GPM.
John Deere 4520 Engine
John Deere 2.4L 4-cyl diesel
Engine details ...
John Deere 4520 Transmissions
12-speed
hydrostatic
Transmission details ...
John Deere 4520 Power
Engine (gross)60 hp
44.7 kW
Gear PTO (claimed)52 hp
38.8 kW
Hydro PTO (claimed)50 hp
37.3 kW
PTO (tested)55.94 hp
41.7 kW
Performance test details ...
Mechanical
Four-wheel drive
Power steering
Wet disc brakes
Cab optional with heat and air-conditioning.
Photos
John Deere 4520
John Deere 4520 photos...
Capacity
ROPS 13.8 Cab} Fuel14.5 gal
54.9 L
Gear Hydraulic system10.3 gal
39.0 L
Hydro Hydraulic system9.6 gal
36.3 L
Hydraulics
Typeopen center
Gear Capacity10.3 gal
39.0 L
Hydro Capacity9.6 gal
36.3 L
Pressure2500 psi
172.4 bar
Valves0 to 5
Pump flow12 gpm
45.4 lpm
Total flow17.1 gpm
64.7 lpm
Steering flow5.1 gpm
19.3 lpm
Tractor hitch
Rear TypeI
Rear lift (at ends)3130 lbs
1419 kg
Rear lift (at 24"/610mm)2500 lbs
1134 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
 540/540e
Mid PTOindependent OptOptional
Mid PTO Type2100
Dimensions & Tires
Wheelbase71.5 inches
181 cm
Weight3855 to 4345 pounds
Front tire8.00-16
Rear tire13.6-28
Full dimensions and tires ...
John Deere 4520 attachments
72" mid-mount mower deck
front-end loader
backhoe
Attachment details ...
4520 Serial Number Location
John Deere 4520 serial number location
Serial number plate on the right side of the tractor frame, above the front axle.
4520 Serial Numbers
2005150101
2006340001
2007440001
2008550001
2009650001
2010750001
2011810001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps70
Battery CCA770
Battery volts12
References
4520 references literature
4000 Series Compact Utility Tractors published in 2009, by John Deere
4000 Series Compact Utility Tractors published in 2011, by John Deere
TWENTY Series Tractors published in 2010, by John Deere
