Tractors > John Deere > 7920

John Deere 7920



John Deere 7920 tractor photo
2003 - 2006
7020 Series
Row-Crop tractor
Series map:
7820
7920
141.0kw
153.0kw
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Waterloo, Iowa, USA
John Deere 7920 Engine
John Deere 8.1L 6-cyl diesel
Engine details ...
John Deere 7920 Transmission
infinitely variable transmission
Transmission details ...
John Deere 7920 Power
Engine (gross)205.2 hp
153.0 kW
Engine (net)197.1 hp
147.0 kW
Engine (max)219.9 hp
164.0 kW
PTO (claimed)170 hp
126.8 kW
Mechanical
Four-wheel drive
Power steering
Hydraulic wet disc brakes
Cab standard.
Photos
No photos of the John Deere 7920 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel103.5 gal
391.7 L
 94.7 gal*With right step
358.4 L
Hydraulic system28.5 gal
107.9 L
Hydraulics
Typeclosed center pressure-flow compensating (PFC)
Capacity28.5 gal
107.9 L
Pressure3046 psi
210.0 bar
Valves7
Pump flow32 gpm
121.1 lpm
SCV flow30 gpm
113.6 lpm
Tractor hitch
Rear Type3/3N
Rear lift10050 lbs
4558 kg
 14000 lbsOptOptional
6350 kg
Front Hitchoptional
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic wet discs
Rear PTO Type540/1000 (1.375)
 1000 (1.75)
Engine RPM540@1950
 1000@1950
Front PTOindependent OptOptional
Front PTO Type540/1000
Dimensions & Tires
Wheelbase112.6 inches
286 cm
Weight17927 lbs
8131 kg
Front tire420/90R30
Rear tire480/80R46
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps150
Batteries2
Battery CCA925
Battery volts12
References
7920 references literature
7020 Series Tractors published in 2004, by John Deere
