John Deere 5100M
| | 2012 - 2022 |
|
| 5M Series | | Utility tractor |
|
| Production |
| Manufacturer | John Deere
|
| Utility tractor |
| Built in Augusta, Georgia, USA |
| Original price was $59,281 in 2014 |
| Mechanical |
| Two- or four-wheel drive |
| Differential lock | electro-hydraulic rear diff lock
|
| Steering | hydrostatic power
|
| Hydraulic wet disc brakes |
| Two-post foldable ROPS with flat operation platform. Optional isolated platform. Optional cab with air-conditioning. Optional deluxe cab with premium sound package and sunroof. |
| Hydraulics |
| Type | open center
|
| Pressure | 2828 psi
195.0 bar
|
| Rear valves | 2 ro 3
|
| Mid valves | 2 or 3
|
| Pump flow | 18.4 gpm
69.6 lpm
|
| Total flow | 24.7 gpm
93.5 lpm
|
| Steering flow | 6.3 gpm
23.8 lpm
|
| Steering press. | 2030 psi
140.0 bar
|
| Tractor hitch |
| Rear Type | 2/1
|
| Control | position control and lower-link draft sensing
|
| Rear lift (at 24"/610mm) | 4,793 lbs
2174 kg
|
| | 5,935 lbs (optional)
2692 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic wet disc
|
| Rear PTO Type | 540/540E
|
| | 540 (SyncShuttle)
|
| Engine RPM | 540@2100
|
| 5100M Serial Number Location |
 |
| Serial number plate on the right side of the tractor frame, above the front axle. |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 70 (ROPS)
|
| | 90 (cab)
|
| Battery volts | 12
|
| References |
 |
| 5M Series published in 2013, by John Deere |
