John Deere 5101E



John Deere 5101E tractor photo
2008 - 2012
Model year
5E Limited Series
Utility tractor
Series map:
5093E
5101E
93.0hp
101.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Augusta, Georgia, USA
Original price$51,779 (2012)
Variants
5101Eutility chassis
5101ENnarrow chassis
John Deere 5101E Engine
John Deere 4.5L 4-cyl diesel
Engine details ...
John Deere 5101E Transmission
12-speed partially synchronized
Transmission details ...
John Deere 5101E Power
Engine (gross)101 hp
75.3 kW
PTO (claimed)86 hp
64.1 kW
Mechanical
Four-wheel drive
Steeringhydrostatic power
Independent hydraulic wet disc brakes
Cab standard with heat and air-conditioning.
Photos
No photos of the John Deere 5101E are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel33.5 gal
126.8 L
Front hubs0.74 qts
0.7 L
Front diff.4.8 qts
4.5 L
Hydraulics
Typeopen center
Rear valves2 or 3
Mid valves2 (optional)
Pump flow15.9 gpm
60.2 lpm
Total flow22.5 gpm
85.2 lpm
Steering flow6.6 gpm
25.0 lpm
Tractor hitch
Rear Type2
Controlposition control and top-link draft sensing
Rear lift (at 24"/610mm)3,213 lbs
1457 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/540E
Dimensions & Tires
Wheelbase85.8 inches
217 cm
Weight7,320 lbs
3320 kg
Front tire12.4-24
Rear tire18.4-30
Full dimensions and tires ...
John Deere 5101E attachments
front-end loader
Attachment details ...
5101E Serial Numbers
Location:Left side of tractor above front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps90
 120 (optional)
Battery CCA750
Battery volts12
References
5101E references literature
5D - 5E - 5E Limited Tractors published in 2012, by John Deere
