Tractors > John Deere > 6105R

John Deere 6105R



John Deere 6105R tractor photo
2012 - 2014
6R Series
Utility tractor
Series map:
6105R
6115R
105.0hp
115.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
Original price$86,076 (2014 PowrQuad 2WD )
$114,787 (2014 IVT 4WD )
John Deere 6105R Engine
John Deere 4.5L 4-cyl diesel
Fuel tank58 gal
219.5 L
Engine details ...
John Deere 6105R Transmissions
16-speed partial power shift
24-speed partial power shift
infinitely variable transmission
Transmission details ...
John Deere 6105R Power
Engine (gross)105 hp
78.3 kW
PTO (claimed)86 hp
64.1 kW
Drawbar (tested)78.7 hp
58.7 kW
PTO (tested)105.3 hp
78.5 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Differential lockhydraulic rear lock
Steeringhydrostatic power
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
ComfortView cab standard with air-conditioning. GreenStar and AutoTrac ready with ISOBUS connector.
Photos
No photos of the John Deere 6105R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeload-sensing pressure flow compensated
Pump flow30 gpm
113.6 lpm
SCV flow26.4 gpm
99.9 lpm
Tractor hitch
Rear Type2/3N
Controlelectronic lower-link draft sensing
Rear lift (at 24"/610mm)4,755 lbs
2156 kg
DrawbarCategory 2 swinging drawbar with hammerstrap
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic wet disc
Rear PTO Type540/1000 (1.375)
 540/540E/1000 (optional)
Dimensions & Tires
Wheelbase101.6 inches
258 cm
Weight13030 lbs
5910 kg
Front tire10.00-16
Rear tire16.9R30 (2WD)
Full dimensions and tires ...
John Deere 6105R attachments
front-end loader
Attachment details ...
6105R Serial Numbers
Location:Serial number plate on right side of main tractor frame.
Electrical
Groundnegative
Charging systemalternator
Charging amps120
 200 OptOptional
Battery volts12
Battery AH154
References
6105R references literature
6R Series Tractors published in 2012, by John Deere
