John Deere 6920S Premium
|
|
| Production | |
| Manufacturer | John Deere |
| Utility tractor | |
| John Deere 6920S Premium Engine | |
| John Deere 6.8L 6-cyl diesel | |
| Fuel tank | 66.1 gal 250.2 L |
 Engine details ... | |
| John Deere 6920S Premium Transmission | |
| 20-speed partial power shift | |
 Transmission details ... |
| John Deere 6920S Premium Power | |
| Engine (net) | 160 hp 119.3 kW |
| PTO (claimed) | 141 hp 105.1 kW |
| 136 hp (stationary) 101.4 kW | |
| Mechanical | |
| Four-wheel drive | |
| Steering | hydrostatic power |
| Wet disc brakes | |
| Cab standard. | |
| Photos | |
| No photos of the John Deere 6920S Premium are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center load sensing |
| Pressure | 2900 psi 200.0 bar |
| Pump flow | 25.4 gpm 96.1 lpm |
| Tractor hitch | |
| Rear Type | II/IIIN |
| Rear lift | 18,520 lbs 8400 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| Weight | 12,965 lbs 5880 kg |
| Front tire | 16.9R28 |
| Rear tire | 20.8R38 |
 Full dimensions and tires ... | |
| 6920S Premium Serial Numbers | |
| Location: | Right side of main tractor frame. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 90 |
| 115 | |
| Battery volts | 12 |
| References | |
 | |
| 6020 Series published in 2003, by John Deere |
