Production | |
Manufacturer | John Deere |
Utility tractor |
John Deere 6820 Premium Engine | |
John Deere 6.8L 6-cyl diesel | |
Fuel tank | 66.1 gal 250.2 L |
Engine details ... |
John Deere 6820 Premium Transmission | |
20-speed partial power shift | |
Transmission details ... |
John Deere 6820 Premium Power | |
Engine (net) | 135 hp 100.7 kW |
PTO (claimed) | 122 hp 91.0 kW |
Mechanical | |
Four-wheel drive | |
Steering | hydrostatic power |
Wet disc brakes | |
Cab standard. |
Hydraulics | |
Type | closed center load sensing |
Pressure | 2900 psi 200.0 bar |
Pump flow | 25.4 gpm 96.1 lpm |
Tractor hitch | |
Rear Type | II/IIIN |
Rear lift | 18,520 lbs 8400 kg |
Power Take-off (PTO) | |
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
Weight | 12,304 lbs 5581 kg |
Front tire | 16.9R28 |
Rear tire | 20.8R38 |
Full dimensions and tires ... |
6820 Premium Serial Numbers | |
Location: | Right side of main tractor frame. |
Electrical | |
Ground | negative |
Charging system | alternator |
Charging amps | 90 |
  | 115 |
Battery volts | 12 |
References | |
6020 Series published in 2003, by John Deere |
