John Deere 6620 Premium
|
|
| Production | |
| Manufacturer | John Deere |
| Utility tractor | |
| John Deere 6620 Premium Engine | |
| John Deere 6.8L 6-cyl diesel | |
| Fuel tank | 54.7 gal 207.0 L |
 Engine details ... | |
| John Deere 6620 Premium Transmission | |
| 24-speed partial power shift | |
 Transmission details ... |
| John Deere 6620 Premium Power | |
| Engine (net) | 125 hp 93.2 kW |
| PTO (claimed) | 110 hp 82.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Steering | hydrostatic power |
| Wet disc brakes | |
| Cab standard. | |
| Hydraulics | |
| Type | closed center load sensing |
| Pressure | 2900 psi 200.0 bar |
| Pump flow | 25.4 gpm 96.1 lpm |
| Tractor hitch | |
| Rear Type | II/IIIN |
| Rear lift | 16,360 lbs 7420 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| Weight | 11,532 lbs 5230 kg |
| Front tire | 14.9R28 |
| Rear tire | 18.4R38 |
 Full dimensions and tires ... | |
| 6620 Premium Serial Numbers | |
| Location: | Right side of main tractor frame. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 90 |
| 115 | |
| Battery volts | 12 |
| References | |
 | |
| 6020 Series published in 2003, by John Deere |
