Tractors > John Deere > 7515

John Deere 7515



John Deere 7515 tractor photo
2005 - 2010
Utility tractor
Series map:
6615
7515
89.7kw
104.4kw
Production
ManufacturerJohn Deere
Utility tractor
Built in Montenegro, Brazil
John Deere 7515 Engine
John Deere 6.8L 6-cyl diesel
Engine details ...
John Deere 7515 Transmission
16-speed partial power shift
Transmission details ...
John Deere 7515 Power
Engine140 hp
104.4 kW
PTO (claimed)119 hp
88.7 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic
Steeringhydrostatic power
Hydraulic wet disc brakes
Cab optional.
Photos
No photos of the John Deere 7515 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel81 gal
306.6 L
Hydraulic system16.9 gal
64.0 L
Front axle8.7 qts
8.2 L
Front hubs1.8 qts (each)
1.7 L
Hydraulics
Typeclosed-center load sensing
Capacity16.9 gal
64.0 L
Pressure2756 psi
190.0 bar
Valves2 to 3
Pump flow26.4 gpm
99.9 lpm
SCV flow25.4 gpm
96.1 lpm
Oil type
JD Hy-Gard
Tractor hitch
Rear TypeII
Controlelectronic lower link
Rear lift (at ends)10,690 lbs
4848 kg
Rear lift (at 24"/610mm)6,500 lbs
2948 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/1000
Dimensions & Tires
Wheelbase104.3 inches
264 cm
Front tire18.4-26
Rear tire24.5-32
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps90
Battery volts12
Battery AH150
References
7515 references literature
6415, 6615 & 7515 Tractors published in 2004, by John Deere
